Basic parameters

• Length*Width*Height (mm)

  8940*2420*3140

• Inner height (mm)

  2460mm (front passage of mid-door)
  1820mm (rear passage of mid-door)

• Wheelbase (mm)

  4350

• Front/rear overhang (mm)

  2000/2590

• Tire

  265/70R19.5

• Min turning diameter (m)

  ≤16

• Standard number of seats

  18

• Max number of seats

  19

• Max manufacturer's total mass (kg)

  13400

• Front/rear axle (kg)

  4700/8700

Powertrain

• Energy storage device

  Fuel tank 120L + supercapacitor 16 in series

• Rated power (kW/rpm)

  132/2300

• Rated torque (N·m/rpm)

  650/1200-1900

• Displacement (L)

  4.156

• Emission

  Euro III

Seat

• Wheelchair area ( for city bus)

  ●

• 3-point full air-suspended driver seat

  ●

Interior

• Curtain

  ●

• Front windshield half-width manual support rod sunshade, manual sunshade at driver side

  ●

• Driver's rear enclosure

  ●

• Manual wheelchair ramp

  ●

• Roof hatch without ventilator

  ●

Exterior

• First passenger door: single-leaf pneumatic inward swing door

  ●

• Second passenger door: double-leaf pneumatic inward swing door

  ●

• Single-layer sliding window, sealed glass at both ends

  ●

• Movable built-in driver window

  ●

• Front windshield laminated glass

  ●

A/C

• Cooling-only

  ●

• Heater

  —

• Non-independent three-wall-mounted forced cooling fin

  ○

• Natural air defrosting

  ●

• Low-power water heating defrosting

  ○

Chassis

• Front disc and rear disc

  ●

• Air suspension

  ●

• Steering wheel

  RHD

Safety and driving assistance system

• Electronic Braking System (EBS)

  ●

• EPB

  ●

• Manual rod-type rearview mirror

  ●

• Electric rod-type rearview mirror (with electric defrosting)

  ○

• Reversing radar

  —

• 2 x 2kg fire extinguishers

  ●

Audio-visual entertainment and lighting

• Molead LCD instrument

  ●

• Front and rear LED rolling electronic destination boards

  ●
